13MP M6.5 Lens
1/3.1" COB Lens
1/3.1" 13MP COB F2.2 DFOV 87.6 Degree M6.5 InnoMaker Lens
IMT Model No.  IMT-1A65H005-N


  Lens Model IMT-1A65H005-N
  Sensor Format 1/3.1"
  Resolution 13 MP
  Sensor Type COB
  Structure 5P
  Max Image Circle Ø5.8
  F/NO. 2.2 +/- 5%
  EFL (mm) 3.05
  TTL (mm) 4.60
  FOV Field of View
  Diagonal DFOV 87.6°
  Horizontal HFOV 74.9°
  Vertical VFOV 59.4°
  TV Distortion <1%
  CRA <34.9°
  Lens Filter None
  Barrel M6.5*P0.25
  KLT Camera Modules KLT-OIS-USB1A-IMX258 V1.0
  Use IMT Made Lenses KLT-D3MA-IMX258 V5.0


        IMT Lens Specification Sheet









         IMT Lens on KLT Camera Modules


        SONY IMX258 USB Interface Auto Focus 13MP Camera Module, Micro Gimgal Stabilizer, Optical Image Stabilization (OIS) Platform
        Model No.   KLT-OIS-USB1A-IMX258 V1.0


 Camera Module No. KLT-OIS-USB1A-IMX258 V1.0
 Image Sensor IMX258 Output Format: MJPG, YVY2, H.264
 Stabilizer Micro Gimbal Stabilizer (MGS) 60 FPS 640 x 480 (VGA)
 EFL 3.05 mm 30 FPS 1280 x 720 (HD 720P)
 F.NO 2.2 30 FPS 1920 x 1080 (Full HD)
 Pixel 4224 x 3192 20 FPS 4224 x 3192 (13MP)
 View Angle 87.6° Supporting OS
 Lens Type 1/3.06 inch Windows 7, 8.1, 10,Vista
 Lens Dimensions 19.00 x 19.00 x 9.90 mm Windows XP SP2 under UVC
 Module Size 39.00 x 19.00 mm Linux Kernel V2.6.2.1 or later
 Module Type Auto Focus MAC OS 10.4 or later
 IMT Lens Model IMT-1A65H005-N Operating Voltage: 5V +/- 5%
 Interface USB 2.0 Compliant with UVC Version 1.0
 USB Extension Cable KLT-USB3A-Cable U-Green Style Extension Cable



        SONY IMX258 MIPI Interface Auto Focus 13MP Camera Module
        Model No.   KLT-D3MA-IMX258 V5.0


   Camera Module No. KLT-D3MA-IMX258 V5.0
   Image Sensor IMX258
   EFL 3.05 mm
   F.NO 2.2
   Pixel 4224 x 3136
   View Angle 87.6°
   Lens Type 1/3.06 inch
   Lens Dimensions 8.50 x 8.50 x 5.65 mm
   Module Size 100.00 x 8.50 mm
   Module Type Auto Focus
   Interface MIPI
   IMT Lens Model IMT-1A65H005-N
   Mating Connector BBR43-30KB533
